TUG MZ - Page 165

4-2-27
Rev 3
CD373
Chapter 4
MZ Tow Tractor Section 2
Table 2-11. Hydraulic Pump Installation
Fig &
Ind
Tug Part
Number
Description Qty Effective
11-1 M3-1-8026 Pump Assembly, Power Steer, 72V OHIO 1 1 & Up
11-2 5/16-18 Nut, Flange 5/16-18 8 "
11-3 MX4-10231 Mount, Isolator, Rubber 4 "
11-4 MX4-10084 Mount, Power Steer Pump, Modified 1 "
11-5 5/16-18 Nut, Flange 5/16-18 4 "
11-6 5/16 Washer, Flat 5/16" ID 4 "
11-7 5/16-18 x 1¼ Bolt, Hex Head Ø 5/16-18 x 1¼" Long 4 "
