TUG MZ - Page 169

4-2-31
Rev 3
CD373
Chapter 4
MZ Tow Tractor Section 2
Table 2-13. Controller Assembly
Fig &
Ind
Tug Part
Number
Description Qty Effective
13- MZ-10008 Controller Component Kit 1 1 & Up
13-1 10-32 x 1 Bolt, Countersunk Ø 10-32 x 1" Long 4 "
13-2 ¼-28 x ¾ Bolt, Hex Head Ø ¼-28 x ¾" Long 4 "
13-3 ¼-28 x 1¼ Bolt, Hex Head Ø ¼-28 x 1¼" Long 4 "
13-4 M8-1¼ x 16 Bolt, Hex Head Ø M8-1¼ x 16mm Long 5 "
13-5 M8 Washer, Lock M8 ID 5 "
13-6 ¼ Washer, Lock ¼" ID 8 "
13-7 MZ-10008-1 Controller, AC Motor 1 "
13-8 MZ-10008-10 Panel, Controller Mount 1 "
13-9 MZ-10008-11 Bar, Buss, L/H 1 "
13-10 MZ-10008-12 Bar, Buss, R/H 1 "
13-11 MZ-10008-13 Bar, Buss, Small 1 "
13-12 MZ-10008-2 Converter, DC/DC 1 "
13-13 MZ-10008-3 Fuse, 50 Amp 1 "
13-14 MZ-10008-4 Fuse, 355 Amp 1 "
13-15 MZ-10008-5 Holder, Fuse 2 "
13-16 MZ-10008-6 Contactor, 80 Amp 1 "
13-17 MZ-10008-7 Bracket, 80 Amp, Contactor Mount 1 "
13-18 MZ-10008-8 Contactor 200 Amp 1 "
13-19 MZ-10008-9 Bracket, 200 Amp, Contactor Mount 1 "
13- MZ-10083 Software, Curtis Programming (Service Item) 1 As Req'd
