Pag. 27
PMS701 HS-TR
STD version
Lista ricambi
Spare parts
Part N° Ref. N° Designation Q.ty Spare part KIT
Teil-Nr Bestell-Nr Bezeichnung M.ge
Posiz. Codice Descrizione Q.tà KIT ricambi
42 AE0.0029 Retaining ring / Sicherungsring / Seeger per albero 1 ►K7S.0527.0
UNI7435 D.30
47 AT1.0048 Seal ring / Siegelring/ Anello tenuta 1 ►K7S.0307.0
TIPO AS 40x68x8 VITON
48 AT4.0009 Shaft seal / Wellendichtring / Anello tenuta 1 ►K7S.0307.0
A 30x40x7 VITON
49 AT4.0010 Shaft seal / Wellendichtring / Anello tenuta 1 ►K7S.0307.0
A 50x80x8 DIN 3760 VITON ►KIT.7013.0
50 AT5.0058 O-ring / O-ring / O-ring 1 ►K7S.0307.0
OR3925 Di=234.62x2.62
51 AT5.0114 O-ring / O-ring / O-ring 1 ►K7S.0307.0
OR2118 29.87x1.78
52 AT9.0035 V-ring / V-ring / V-ring 1 ►KIT.7013.0
cr400251 VR2 24-27 ►K7S.0307.0
60 DIF.0002 Differential gear / Differentialgetriebe/ Differenziale 1 ►K7S.0527.0
62 GRA.0002 Grub screw / Dübel / Grano testa piana 1 ►K7S.0527.0
M6x10 UNI5923
69 MOT.0031 Motor / Motor / Motore asincrono 1 ►K7S.0527.0
71 RO1.0014 Kasher / Scheibe / Rondella rame 2 ►K7S.0524.0
(M14) ►K7S.0525.0
79 TAP.0046 Breather plug / Sicherheitsventil / Tappo sfiato 2 ►K7S.0524.0
M14x1.5 (TSF 1M) ►K7S.0525.0
81 VC1.0002 Socket head cap screw / Schraube / Vite TCEI 4 ►K7S.0111.0
M12x40 8.8 nera
83 VC1.0053 Socket head cap screw / Schraube /Vite TCEI 3 ►K7S.0525.0
M6x14 - 8.8 nera
85 VC1.0078 Socket head cap screw / Schraube / Vite TCEI 22 ►K7S.0111.0
M12x70 8.8 nera UNI 5931
86 VC1.0085 Socket head cap screw / Schraube / Vite TCEI 6 ►K7S.0111.0
M8x40 12.9 nera
Tab. B
Lista ricambi: differenziale / ruota fonica
Spare parts list: differential gear / tone wheel
