4a — MONITOR MENU
Monitor Menu: OUTPUTS
DISPLAY
VARIABLE RANGE DESCRIPTION
Analog Out 0–10.0 V Voltage at Analog output (pin 30).
Analog_Output 0–32767
Digital Out 6
On/Off Digital Out 6 output on or off (pin 19).
Dig6_Output On/Off
Digital Out 7
On/Off Digital Out 7 output on or off (pin 20).
Dig7_Output On/Off
Driver 1 PWM
0–100 % Driver 1 PWM output (pin 6).
PWM1_Output 0–32767
Driver 2 PWM
0–100 % Driver 2 PWM output (pin 5).
PWM2_Output 0–32767
Driver 3 PWM
0–100 % Driver 3 PWM output (pin 4).
PWM3_Output 0–32767
Driver 4 PWM
0–100 % Driver 4 PWM output (pin 3).
PWM4_Output 0–32767
PD PWM
0–100 % Proportional driver PWM output (pin 2).
PD_Output 0–32767
PD Current
0–2.0 A Current at proportional driver (pin 2).
PD_Current 0–607
5 Volts
0–6.25 V Voltage at +5V output (pin 26).
5_Volts_Output 0–1023
Ext Supply Current
5–200 mA Combined current of the external +12V and
Ext_Supply_Current 52–800 +5V voltage supplies (pins 25 and 26).
Pot Low
0–6.25 V Voltage at pot low (pin 18).
Pot_Low_Output 0–1023
