Guidelines for Station Planning
D301087 0308 - BL20 CANopen6-8
If the power supply from the module bus is not guaranteed, thereby
making a further Bus Refreshing module necessary, the software
Module Supply Nominal current
consumption
BL20-2DO-24VDC-0.5A-P 32 mA
BL20-2DO-24VDC-0.5A-N 32 mA
BL20-2DO-24VDC-2A-P 33 mA
BL20-4DO-24VDC-0.5A-P 30 mA
BL20-E-8DO-24VDC-P 15 mA
BL20-16DO-24VDC-0.5A-P 120 mA
BL20-E-16DO-24VDC-P 25 mA
BL20-32DO-24VDC-0.5A-P 30 mA
BL20-1AO-I(0/4...20MA) 39 mA
BL20-2AO-I(0/4...20MA) 40 mA
BL20-2AO-U(-10/0...+10VDC) 43 mA
BL20-2DO-R-NC 28 mA
BL20-2DO-R-NO 28 mA
BL20-2DO-R-CO 28 mA
BL20-1CNT-24VDC 40 mA
BL20-1RS232 140 mA
BL20-1RS485/422 60 mA
BL20-1SSI 50 mA
BL20-2RFID 30 mA
BL20-E-1SWIRE 60 mA
