I/O-ASSISTANT generates an error message when the user acti-
vates the command “Station → Verify“.
Note
Bus Refreshing modules which do not supply the gateway with
power are to be combined with either a BL20-P3T-SBB-B or a
BL20-P4T-SBBC-B (tension clamp connection) base module or with
the base modules BL20-P3S-SBB-B or BL20-P4S-SBBC-B (screw
connection).
Figure 6:
Power supply at
BL20-GWBR-
CANOPEN
Figure 7:
Power supply at
BL20-GW-
CANOPEN
