Tynetec Advent xt - Pa Amplifier & Smpsu Installation; Termination; Mains Supply; Installation

DocNo.FM0410issueM‐1Page14
100V LINE AUDIO
240V AC
MAINS
EN
AUD
0V
VR2
AUD IO VOL
PA AMPLIFIER
BOARD
TONE VOL
VR1 FIRE
ISSUE "E" ONWARD
+24V/50W DC-DC CONVERTER -24V/50W DC-DC CONVERTER
15V/100W SWITCH MODE PSU
TRANSFORMER
12V BATTERY
PA1 PA2
AUDIO OUT
AUDIO & DATA IN
8.PAAMPLIFIER&SMPSUINSTALLATION


TheoptionalPAamplifier&SMPSU(P/No.ZXT155)allowsthe
onsitemanagertobroadcastpublicaddressannouncements
throughallintercomssimultaneously.

Note;PAintercoms(P/No.ZXT206)mustbefittedinall
dwellings.OnePAamplifier&SMPSUcandriveapprox.80
intercoms,forlargersystemsasecondZXT155will
berequired
andthesitePAwiringmustbesplitintotwolegs.
















INSTALLATION

ThePAamplifier&SMPSUishousedinasinglesteelenclosure200x500x100mm(HxWxD)designedforwallmounting
belowtheAdventxtcontroller.

MAINS SUPPLY

The240VACmainssupplyshouldbetakenfromthesamefusedspurastheAdventxtcontroller.Fitthenylonstrainrelief
tothesockettopreventthemainsleadbeinginadvertentlyunplugged.

TERMINATION

3cablesareprovidedforconnectiontotheAdventxtterminationboard‐seetablebelowforconnectionsandcolour
codes.SeeDrgNo.ZXT100sheet2,forlargersystemswithintercomssplitover2legsseeDrgNo.WD0276.

Terminal Colour Cable ConnectedTo:

PAAmplifierEN Red
3Core
AdventxtTerminationBoardEN
PAAmplifierAUD Blue AdventxtTerminationBoardAUD
PAAmplifier0V Green AdventxtTerminationBoard0V

RS485+ Red
2Core
AdventxtTerminationBoardRS485+
RS485‐ Black AdventxtTerminationBoardRS485‐

TransformerPA1 Red
2Core
AdventxtTerminationBoardPA1
TransformerPA2 Black AdventxtTerminationBoardPA2

Note:thetransformerPA1/PA2connectionisnotpolarityconscious.

SMPSU & DC-DC MODULES

The15V/100Wswitchmodepowersupplyunit(P/No.W00585)isfactorysetto13.75VDCoutputtosupplythetwo24V
DC‐DCconvertersandthePAamplifierboard.Thisvoltagealsochargesthe12Vstandbybattery.TheSMPSUhas an 
internal20mm3.15Amainsfuseandsolidstateoverloadprotectionontheoutput.Fordetailsonchangingthemainsfuse
see“27VSMPSUModule”onPage7.

Thetwo24V/50WDC‐DCconvertermodules(P/No.W00590)arefactorywiredtoprovide+/‐24VDCsupplyforthePA
amplifierboard.TheDC‐DCconvertershavesolidstateoverloadprotectionandcontainnouserserviceableparts.

PROGRAMMING

TheAllCallandFireToneoptionsmustbeenabledinthe“GeneralSetup”programming‐seetheAdventxtProgramming
Manual(TynetecDocNo.FM0411).

