Tynetec Advent xt - Digital Door Panel Installation; Digital Door Panels

DocNo.FM0410issueM‐1Page30
21.DIGITALDOORPANELINSTALLATION

TheAdventxtsystemcanbeupgradedtoincludeadoorentryfacilitywiththeadditionofdigitaldoorpanelsand
telephonehandsets.Visitorscancallresidentsdirectfromthedoorpanelswithfullduplexspeechviadoorentry
telephones.TheonsiteManagercanbecontactedviatheDECT(or
fixedCLItelephones)bypressingthedoorpanel
“Manager”button‐thistypeofcallwillalsooperateinLocalOffsiteorRemoteOffsitemode.Inallmodesofoperationan
electriclockreleasecanbeactivatedtoallowvisitorsaccess.

The“Trade”buttoncanallowaccessduring3programmabletimeperiodseachdayandthe“Code”buttoncanbeused
withaprogrammable4digitaccesscodetoallowaccessatanytime(orduring3programmableperiods)eachday.

Thedoorentrymodecanbesettoallowcallstoresidents24hoursadayortoautomaticallytransferallcallstothe
Managerduringtheeveningandnight.Inaddition,ifaresidentisawaytheircallscanbetemporarilytransferredtoa
neighbourortheManager.

DIGITAL DOOR PANELS

Upto16digitaldoorpanels(P/No.ZSD411)canbeconnectedtothe Adventxtcontroller.AlocalPSUisrequiredateach
doortoprovidepowerfortheelectriclockrelease.A“presstoexit”pushbuttonandadoorstatuscontactcanalsobe
connectedlocallyintoeachdoorpanel.



Thebackboxshouldbeorientatedwiththesingle
Earthstudinthetoplefthandcorner.

Donotcutaholeinthetopfaceofthebackboxfor
cableentry‐thismayallowwatertoenterand
 damagetheelectroniccomponentsorkeypad.

Cableentryintothebackboxshouldbethrough
anyofthe20mmknockoutsprovided.

Important:thebackboxandfasciamustbeconnected
totheMainsEarthterminalusingaminimum
of2.5mm
2
cable.


INSTALLATION

Thestandardbackboxisdesignedforflushmounting‐astainlesssteelsurfacecowling(P/No.HM1140)isavailable
separately.Thefasciaisfixedby6No.M5x12mmscrewswhichrequire a3mmAllenkey.

Acut‐out415mmhighx170mmwidex70mmdeepwillallowthebackboxtofitflushintothewallordoorscreenwiththe
bezeloverlappingbyapprox10mmonallsides.

Aseparate6paircableshouldbeinstalledbetweeneachdoorpanelandtheAdventxtcontroller(ie.notlooped‐offthe
systemnetwork).Aseparate1.0mmpairshouldbeusedforlockpower.Thebackboxandfasciamustbebondedtothe
fusedspurEarthterminalwithaminimumof2.5mm
2
cableinlinewithcurrentIEEregulations.

IMPORTANTNOTE:thedoorpanelrequiresa12VDCsupply‐NOT24VDC.

FERRITE CORE

Thedoorpanelwiringmustbeloopedthroughthe
ferritecoreinsidethebackbox.

Thiswillsuppressanyvoltagetransientsinduced
onthewiringandgreatlyreducethelikelihood
ofdamagetotheCPU.







