DocNo.FM0410issueM‐1Page7
TERMINATION
BOARD
BATTERY BATTERY
SMPSU
MODULE
PSTN
LINE
DECT
2 x MASTER
BT SOCKETS
BT LINE
IN
BASE
TO DECT
STATIONS
BT LEADS
SUPPLIED
3.CONTROLLERINSTALLATION

27V SMPSU MODULE

Thecontrollerincludesa27V/150W(5.6A)switchedmodepowersupplyunitwithsolidstateoverloadprotection.Withthe
mainssupplyONthegreenoutputhealthyLEDshouldbeilluminated.The outputvoltage isfactorysetto27.5VDC(with
thebatteriesdisconnected)usingaDVMacrossV+/V‐.














BATTERY STANDBY

Intheeventofamainsfailure,two12V5Ahrechargeablebatterieswillmaintainatypical
systemforapprox.8hours.Aprotectioncircuitwilldisconnectthebatterysupplyinthe
eventofprolongedmainsfailuretopreventdamagetothebatteries.Themainssupply
mustbeappliedfirsttoenergisetheprotectioncircuit,i.e.thesystemwillnotfunction
bysimplyconnectingthebatteriesalone.

TELEPHONE CONNECTION

TwoBTmastersockets(notsupplied)arerequiredtoconnecttheexternaltelephonelineandthelocalDECTbase
stations/fixedCLItelephonestothecontroller.
























ThePSTNlineshouldbeterminatedinamastersocketbythetelephonecompany.Connecta2pairCW1308speccable
fromthesecondmastersocket(terminals2,3&5)totheDECTbasestation,MatrixIPPBXorfixedtelephonesocketson
thescheme.Noteamaximumof4devicescanbeconnectedtotheAdventxt.









27V/150WSMPSU
(W00581)
27VOUTPUTHEALTHYLED 27VADJUST
MAINSLIVE
MAINSNEUTRAL
MAINSEARTH
0V
0V
27.5VDC
27.5VDC
