33.KIRK400MULTICELLDECT‐REPEATERDEPLOYMENT

REPEATER DEPLOYMENT RULES

 Amaximumof3RepeaterscanbeconfiguredonaKirk400MultiCellWirelessServer(KWS400)‐RPN3
 Ifyouhaveupto3RepeatersonaKirk400MultiCell
WirelessServertheyshouldbenumbered:67,131and195
i.e.RPN3+64,+128and+192
 Amaximumof3RepeaterscanbeconfiguredonaIP12ChannelBaseStation‐RPN4/5/6
 Ifyouhaveupto3RepeatersonanIP12ChannelBase
Stationtheyshouldbenumberedas:
BaseStationRPN4/5/6+64,+128and+192
 Amaximumof3Repeaterscanbeconfiguredinachain
 2Repeaterscannothavethesamenumber
 Seedeploymentexamplesbelow;RPN=theRadioPartNumber

KWS400/IPBaseisshadedORANGE
RepeatersareshadedGREENRadiohandoverBLUE







1 REPEATER DEPLOYMENT

1Repeaterconnecteddirectly:







2 REPEATER DEPLOYMENT EXAMPLES

2Repeatersconnecteddirectly:







2Repeatersconnectedinachain:







