Tynetec Advent xt - Controller Installation; Mains Supply Connection

DocNo.FM0410issueM‐1Page6
SUPPLY
FUSED SPUR
(UNSWITCHED + NEON)
240V AC
MAI NS
DECT
LINE
PSTN
MODULE
SMPSU
BATTERYBATTERY
FIT CABLE TIE FOR STRAIN RELIEF
CORE
FERRITE
ON/OFF SWITCH
FIT 5A FUSE
FLEX
3 CORE
3.CONTROLLERINSTALLATION


TheAdventxtcontrollerishousedina400x500x75mm(HxWxD)steel
enclosurewithanintegralpowersupplyunitandrechargeable
standbybatteries.
















3x20mm

KNOCKOUTS

ONR/HSIDE








240VAC

MAINSINPUT&

ON/OFFSWITCH




INSTALLATION

Thecontrollershouldbelocatedinadry,secureareawhichiseasilyaccessibleforterminationandfutureservice.To
removethelidundothesinglefixingscrewandunhookoffthetoplocatingslots.Fixthecontrollertothewallusingthe
twokeyholes(228mmverticallybetweencentres).Allsitewiringshouldentertheenclosureviathe20mmknockouts
provided‐undernocircumstancesshouldholesbedrillednearthemaincircuitboardarea.

MAINS SUPPLY CONNECTION

The240VACmainsconnectionshouldbetakenfromthelandlords supplyandterminatedviaanun‐switchedfusedspur
withneonalongsidethecontroller.Thetypicalpowerrequirementforabasic32wayAdventxtsystemis15Watts.


















Connectthecontrollertothefusedspurusingthe3coreflexandIECsocketprovided.Securetheflextothechassisusing
thecabletieprovidedtopreventthemainsleadbeinginadvertentlyunplugged.Thespurshouldbefittedwitha5Afuse.
Iftheflexisreplacedforany
reasonalwaysensuretheferritecoreisre‐fittedascloseaspossibletotheIECsocket.

4x20mm
KNOCKOUTS
ONTOPFACE
