Tynetec Advent xt - Repeater Power Connection; Repeater RPN

DocNo.FM0410issueM‐1Page57
IPBaseStation
RPN4→
Repeater
RPN =XX
Repeater
RPN+64
Repeater
RPN+64
Repeater
RPN+128
Repeater
RPN+64
Repeater
RPN +128
IPBaseStation
RPN4→
IPBaseStation
RPN4→
IPBaseStation
RPN4→
35.KIRK6500DECT‐REPEATERDEPLOYMENT

REPEATER POWER CONNECTION

Repeatersshouldbeconnectedusing 1.0mmpaircabling,ifCW1308isbeingusedthensparepairscanbe doubled ‐up
and/orloopedbacktoformaringcircuittoreducethevoltagedrop.














TypicallythemaximumdistancetoarepeaterviaCW1308shouldnotexceed100metres.
Note:connectamaximumof6Repeatersper12V2APSU.


REPEATER DEPLOYMENT RULES

 Amaximumof3RepeaterscanbeconfiguredonanIP12ChannelBaseStation;RPN=IPAddress
 Ifyouhaveupto3RepeatersonanIP12ChannelBaseStationtheyshouldbenumberedas:
BaseStationNo.“X”+64,+128and+192.ThefirstBase
StationisNo.4,secondNo.5andsoon…
 Amaximumof3Repeaterscanbeconfiguredinachain
 2Repeaterscannothavethesamenumber
 Seedeploymentexamplesbelow;RPN=theRadioPartNumber

IPBaseisshadedPURPLERepeatersareshaded
GREENRadiohandoverBLUE







1 REPEATER DEPLOYMENT

1Repeaterconnecteddirectly:







2 REPEATER DEPLOYMENT EXAMPLES

2Repeatersconnecteddirectly:







2Repeatersconnectedinachain:






4ChannelMultiCellRepeaters
(3perIP12ChannelBaseStation)
240V
AC
12VDCPSUincluding
Standb
y
Batter
y

RepeaterPowerLeadColourCode
YELLOW=12VBLACK=0V
Use1.0mmCable
Max100m
