DocNo.FM0410issueM‐1Page40
26.NETWORKDATAREPEATERINSTALLATION


TheNetworkDataRepeater(P/No.ZXT340)canbeconnected
intotheAdventxtRS485networktoboostthedatasignal
oncablerunsover1200metres.






   POWERIN

   RS485DATAIN

   RS485DATAOUT





INSTALLATION

TheNetworkDataRepeaterishousedinawallmountedABSenclosure;85x170x35mm(HxWxD).

TERMINATION

The24V&0VpowerconnectioncanbetakenfromtheAdventxtnetwork.
CuttheAdventxtnetworkdatawires(TX+/TX‐)atapointbeforethesignalbeginstofail.
ConnectTX+/TX‐FROMtheAdventxtcontrollerintotheRS485INterminals
ConnecttheremainingAdventxtnetworkdatawiresTX+/TX‐intotheRS485OUTterminals.

LINK SETTINGS

LK1‐LK4willnormallybefittedinposition“A”.OnlymoveifadvisedbyTynetecTechnicalSupport.

LinkNo. Function LinkPosition“A” LinkPosition“B”
   
LK1 RS485IN+ 1K2pull‐up opencircuit
LK2 RS485IN‐ 1K2pull‐down opencircuit
LK3 RS485OUT+ 1K2pull‐up opencircuit
LK4 RS485OUT‐ 1K2pull‐down opencircuit

DIL SWITCH SETTINGS
SW1allowsadifferentendofline(EOL)resistancetobesetontheRS485INterminalsdependingonthenumberof
networklegsconnectedtotheAdventxtcontroller.

DILSW1 Function DILSwitchOFF DILSwitchON
   
1 RS485INEOL1Leg opencircuit 120ohm
2 RS485INEOL2Legs opencircuit 270ohm
3 RS485INEOL3Legs opencircuit 390ohm
4 RS485INEOL4Legs opencircuit 680ohm

SW2allowsadifferentendofline(EOL)resistancetobesetontheRS485OUTterminals.Thisisnormallyleftopencircuit.
OnlymoveifadvisedbyTynetecTechnicalSupport.

DILSW2 Function DILSwitchOFF DILSwitchON
   
1 RS485OUTEOL1Leg opencircuit 120ohm
2 RS485OUTEOL2Legs opencircuit 270ohm
3 RS485OUTEOL3Legs opencircuit 390ohm
4 RS485OUTEOL4Legs opencircuit 680ohm




