Tynetec Advent xt - Solo Base; Solo Base Repeater

DocNo.FM0410issueM‐1Page48
SoloBase
RPN3
Repeater
RPN67
Repeater
RPN131
Repeater
RPN195
SoloBase
RPN3
Repeater
RPN35
Repeater
RPN67
Repeater
RPN131
Repeater
RPN195
SoloBase
RPN3
Repeater
RPN99
Repeater
RPN35
Repeater
RPN67
Repeater
RPN131
SoloBase
RPN3
Repeater
RPN131
Repeater
RPN195
Repeater
RPN35
Repeater
RPN67
SoloBase
RPN3
Repeater
RPN67
Repeater
RPN131
Repeater
RPN195
31.KIRK400SOLOBASEDECT‐REPEATERDEPLOYMENT

3 REPEATER DEPLOYMENT EXAMPLES CONTINUED…

3Repeatersconnecteddirectly:












Y‐shaped3Repeaterdeployment:











4 REPEATER DEPLOYMENT EXAMPLES

3Repeatersinachainandthe4
th
connecteddirectly;the3inachainarenumberedasnormal,the4
th
isnumber+32.







2chainsof2Repeaters;theRepeatertotheleftoftheSoloBaseisnumbered+32andtheRepeaterthatconnectstothisis
numbered+96(32+64).







4Repeatersconnecteddirectly;3Repeatersarenumbered+64,+128and+192,the4
th
Repeaterisnumber+32.














