31.KIRK400SOLOBASEDECT‐REPEATERDEPLOYMENT

REPEATER DEPLOYMENT RULES

 Amaximumof6RepeaterscanbeconfiguredonaKirk400SoloBaseWirelessServer(KWS400)RPN3
 Amaximumof3Repeaterscanbeconfiguredinachain
 Ifyouhaveupto3Repeaterstheyshouldbenumbered:67,131and195i.e.RPN3+64,+128and+192
 Ifyouhavemorethan3Repeaterstheyshould
beassignedoneofthefollowing:35,67,99,131,163,195&227
 2Repeaterscannothavethesamenumber
 Seedeploymentexamplesbelow;RPN=theRadioPartNumber

KWS400isshadedREDRepeatersareshadedGREENRadiohandoverBLUE







1 REPEATER DEPLOYMENT

1Repeaterconnecteddirectly:







2 REPEATER DEPLOYMENT EXAMPLES

2Repeatersconnecteddirectly:







2Repeatersconnectedinachain:







3 REPEATER DEPLOYMENT EXAMPLES

3Repeatersconnectedinachain:







1Repeaterconnecteddirectlyand2inachain:











