5.NETWORKLOADCONSIDERATIONS

Itisveryimportanttotakevoltagedropacrossthesystemnetworkintoconsiderationwhenplanninganinstallation.Itis
thecableresistanceonthepowersupplywiringthatgivesrisetovoltagedrop‐thelongerthecablerunandthelargerthe
currentrequirement,thelargerthevoltagedrop.
Toperformadetailedassessmentofvoltagedropiscomplex;youneed
toknowthecurrentrequirementofeachdevice,thedistancebetweeneachdeviceandtheresistanceofthecableper
metre.Toestimatetheworstcasescenariosimplytakethemaximumcablerunandcalculatethevoltagedropasifall
deviceswereattheendofthecable.


TypicalcurrentrequirementsofdevicesconnectedtotheAdventxtnetworkaregivenbelow:

24VNetworkDevices Standby Active
  
StandardIntercomUnit 2mA 10mA
RemoteIntercomUnit 2mA 10mA
CeilingPullcordwith24VLED 0mA 10mA
DoorEntryTelephone 3mA 15mA
DoorEntryTelephonewithLEDon 4.5mA N/A
CombinedIntercom 2mA 70mA
CombinedIntercomwithLEDon 7.5mA N/A
Manager/LiftCallpoint 2mA 10mA
NetworkReceiver 10mA 10mA
StatusModule 12mA 12mA

12VAuxiliaryDevices Standby Active 
  
DigitalDoorPanel 30mA 250mA

EXAMPLE

Theestimatedvoltagedroponaninstallationwith40intercoms,1statusmodule,1managercallpoint,1liftcallpointand6
networkreceiverson400metresofcablewouldbe;

 (40x2mA)+(1x12mA)+(2x2mA)+(6x10mA)=totalcurrent156mA(0.156A)on24Vline

 400metresofCW1308cable=40Ω(10Ωper100metres)

 usingV=IxR:0.156Ax40Ω=6.24Vdropon24Vline(leavingapprox.18V)

Devicesonthe24Vsupplywillworkdowntoapprox.16Vthereforetheabove dropisacceptable.

REDUCING VOLTAGE DROP

Thereareseveralmeansofreducingthevoltagedrop;siteconditionswilldictatewhichisused;

1.Thebestsolutionistosplitthenetworkintoanumberofshortspursratherthanonelongrun.Thishastheadvantageof
smallervoltagedropspercablerunandsimplifiedfaultfinding. 

2.Onlargeinstallationsinstalla1.0mmpowerpairoraCW1308withadditionalsparepairstoallow“doubling‐up”on
powerconductors.Increasingthecablecrosssectionareawillreduceitsresistancethereforereducingtheamountof
voltagedropped.

3.Loopingbackthepowerconductorsfromthelastintercomtothecontrollerwillformaringcircuitwhichwilleffectively
halvetheresistance.

4.Anauxiliarypowersupplycanbeconnectedtothesitewiringatasuitablepointto“jack‐up”thesupplymidwayalong
thecablerun.Thedisadvantageofthisbeingfuture serviceengineersmaynotbeawareofPSU’spresenceandthe
networkwillremainpoweredwhenthecontrollerisswitchedoff.









THERESISTANCEOFCW1308CABLEIS
APPROX100ΩPER1000METRES
