32.KIRK400MULTICELLDECT

TheKirk400multicelloptionissuitableformedium/largesites usingupto4basestationsandupto12repeaters.
Upto12DECTtelephonescanbeusedonamulticellsystemasstandard,upto30withanadditionallicence.

KIRK 400 MULTI CELL CONFIGURATION











SeeTynetecDrgNo.ZXT100issueLsheet8fordetailedconnections

PART NUMBERS


PartNo. Description Notes
  
ZXT548 700VAUPS 1persite
ZXT556 MatrixEternityIPPBX 1persite
ZXT549 16PortFastswitch(8xPoE) 1persite
ZXT504 Kirk400WirelessServer(MultiCell) 1persite
ZXT536 IP12ChannelBaseStation max3persite
ZXT512 2ChannelMultiCellRepeater max12persite
ZXT523 Spectralink7202DECTPhone&Charger
max12(30with
additionallicence)
ZXT524 Spectralink7212DECTPhone&Charger
ZCS766 DeskCLITelephone 1persite
ZCS729 KirkRepeate rProgrammingKit 1offpurchase
W00525 12V2ABoxedPSU 1per6Repeaters
F00040 12V3.4AhRechargeableBattery 1perPSU

POWER CONNECTION

TomaintainDECToperationduringamainsfailurethe MatrixandFastswitchmustbothbepoweredfromthe700VAUPS,
theRepeatersmustbepoweredfromabatterybacked12VDCpowersupply.

IftheMatrixandFastswitcharepluggeddirectlyintothemainsandRepeatersarepoweredviain‐linePSUmodulesthere
willbenoDECTcoverageduringamainsfailure;howeverthefixedCLIdesktelephonewillstilloperate.

FASTSWITCH CONNECTION

The16PortFastswitchprovidesPoweroverEthernetfortheKirk400WirelessServerandIPBaseStations.

POWER‐connecttotheUPSviathein‐linePSUmodule provided.
PORTS1to4‐connecttotheKirk400WirelessServerandIPBaseStations(upto100metresof4pairCat5ecable).
PORT9‐connecttotheMatrixETHERNETportusingtheRJ45patch leadprovided.
