Docξ˜ƒNo.ξ˜ƒFM0410ξ˜ƒissueξ˜ƒM‐1ξ˜ƒPageξ˜ƒ46
ξ˜ƒ30.ξ˜ƒKIRKξ˜ƒ400ξ˜ƒSOLOξ˜ƒBASEξ˜ƒDECTξ˜ƒ
ξ˜ƒ
MATRIX CONNECTION
ξ˜ƒ
Theξ˜ƒMatrixξ˜ƒIPξ˜ƒPBXξ˜ƒinterfacesξ˜ƒtheξ˜ƒAdventξ˜ƒxtξ˜ƒtoξ˜ƒtheξ˜ƒDECT;ξ˜ƒitξ˜ƒalsoξ˜ƒgivesξ˜ƒaccessξ˜ƒtoξ˜ƒanξ˜ƒoutsideξ˜ƒlineξ˜ƒandξ˜ƒallowsξ˜ƒzoningξ˜ƒofξ˜ƒcalls.ξ˜ƒ
ξ˜ƒ
24VDCξ˜ƒβ€ξ˜ƒconnectξ˜ƒtoξ˜ƒtheξ˜ƒUPSξ˜ƒviaξ˜ƒtheξ˜ƒin‐lineξ˜ƒPSUξ˜ƒmoduleξ˜ƒprovided. ξ˜ƒξ˜ƒ
CO1ξ˜ƒβ€ξ˜ƒconnectξ˜ƒtoξ˜ƒtheξ˜ƒAdventξ˜ƒxtξ˜ƒDECTξ˜ƒoutputξ˜ƒusingξ˜ƒtheξ˜ƒRJ11/BTξ˜ƒleadξ˜ƒprovided.ξ˜ƒ
CO2ξ˜ƒβ€ξ˜ƒconnectξ˜ƒtoξ˜ƒanξ˜ƒexternalξ˜ƒlineξ˜ƒusingξ˜ƒtheξ˜ƒsecondξ˜ƒRJ11/BTξ˜ƒleadξ˜ƒprovided.ξ˜ƒξ˜ƒ
SLT1ξ˜ƒβ€ξ˜ƒconnectξ˜ƒtoξ˜ƒtheξ˜ƒfixedξ˜ƒCLIξ˜ƒdeskξ˜ƒtelephoneξ˜ƒviaξ˜ƒaξ˜ƒBTξ˜ƒmasterξ˜ƒsocketξ˜ƒ(Note:ξ˜ƒcutξ˜ƒoneξ˜ƒplugξ˜ƒoffξ˜ƒtheξ˜ƒRJ11/RJ11ξ˜ƒleadξ˜ƒprovided).ξ˜ƒξ˜ƒ
ETHERNETξ˜ƒβ€ξ˜ƒconnectξ˜ƒtoξ˜ƒtheξ˜ƒPoEξ˜ƒinjectorξ˜ƒusingξ˜ƒtheξ˜ƒRJ45ξ˜ƒpatchξ˜ƒleadξ˜ƒprovided. ξ˜ƒ
ξ˜ƒξ˜ƒξ˜ƒξ˜ƒξ˜ƒξ˜ƒξ˜ƒξ˜ƒβ€ξ˜ƒconnectξ˜ƒtoξ˜ƒaξ˜ƒsoundξ˜ƒEarthξ˜ƒterminalξ˜ƒusingξ˜ƒtheξ˜ƒEarthξ˜ƒwireξ˜ƒprovidedξ˜ƒ
ξ˜ƒ
Theξ˜ƒMatrixξ˜ƒisξ˜ƒfactoryξ˜ƒprogrammedξ˜ƒsoξ˜ƒallξ˜ƒincomingξ˜ƒlinesξ˜ƒringξ˜ƒallξ˜ƒextensions.ξ˜ƒIfξ˜ƒanξ˜ƒincomingξ˜ƒlineξ˜ƒisξ˜ƒtoξ˜ƒringξ˜ƒspecificξ˜ƒextensionsξ˜ƒ
thenξ˜ƒtheξ˜ƒMatrixξ˜ƒmustξ˜ƒbeξ˜ƒreconfigured.ξ˜ƒ
ξ˜ƒ
Note;ξ˜ƒinξ˜ƒtheξ˜ƒeventξ˜ƒofξ˜ƒaξ˜ƒmainsξ˜ƒfailureξ˜ƒi.e.ξ˜ƒifξ˜ƒtheξ˜ƒUPSξ˜ƒbatteriesξ˜ƒrunξ˜ƒflatξ˜ƒorξ˜ƒifξ˜ƒaξ˜ƒUPSξ˜ƒisξ˜ƒnotξ˜ƒfitted,ξ˜ƒtheξ˜ƒMatrixξ˜ƒconnectsξ˜ƒCO1ξ˜ƒtoξ˜ƒSLT1ξ˜ƒ
andξ˜ƒtheξ˜ƒAdventξ˜ƒxtξ˜ƒwillξ˜ƒonlyξ˜ƒringξ˜ƒtheξ˜ƒfixedξ˜ƒCLIξ˜ƒdeskξ˜ƒtelephone.ξ˜ƒ
ξ˜ƒ
KIRK 400 WIRELESS SERVER (SOLO BASE) PROGRAMMING
ξ˜ƒ
Theξ˜ƒMatrixξ˜ƒmustξ˜ƒhaveξ˜ƒitsξ˜ƒIPξ˜ƒaddressξ˜ƒsetξ˜ƒtoξ˜ƒ192.168.0.2ξ˜ƒ
Theξ˜ƒKirkξ˜ƒ400ξ˜ƒWirelessξ˜ƒServerξ˜ƒmustξ˜ƒhaveξ˜ƒitsξ˜ƒIPξ˜ƒaddressξ˜ƒsetξ˜ƒtoξ˜ƒ192.168.0.3ξ˜ƒandξ˜ƒitsξ˜ƒRadioξ˜ƒPartξ˜ƒNumberξ˜ƒsetξ˜ƒtoξ˜ƒ3.ξ˜ƒ
ξ˜ƒ
ADVENT xt PROGRAMMING
ξ˜ƒ
Theξ˜ƒPBXξ˜ƒRingξ˜ƒmustξ˜ƒbeξ˜ƒenabledξ˜ƒinξ˜ƒtheξ˜ƒβ€œGeneralξ˜ƒSetupβ€ξ˜ƒprogrammingξ˜ƒβ€ξ˜ƒseeξ˜ƒtheξ˜ƒAdventξ˜ƒxtξ˜ƒProgrammingξ˜ƒManualξ˜ƒ(Tynetecξ˜ƒDocξ˜ƒ
No.ξ˜ƒFM0411).ξ˜ƒ
ξ˜ƒ
2 CHANNEL MULTI CELL REPEATERS
ξ˜ƒ
Aξ˜ƒmaximumξ˜ƒofξ˜ƒsixξ˜ƒ2ξ˜ƒChannelξ˜ƒMultiξ˜ƒCellξ˜ƒRepeatersξ˜ƒcanξ˜ƒbeξ˜ƒusedξ˜ƒwithξ˜ƒtheξ˜ƒKirkξ˜ƒ400ξ˜ƒWirelessξ˜ƒServerξ˜ƒSoloξ˜ƒBase.ξ˜ƒRepeatersξ˜ƒ
requireξ˜ƒaξ˜ƒpowerξ˜ƒconnectionξ˜ƒonly;ξ˜ƒtheyξ˜ƒcommunicateξ˜ƒwithξ˜ƒtheξ˜ƒSoloξ˜ƒBaseξ˜ƒvia ξ˜ƒlowξ˜ƒpowerξ˜ƒradioξ˜ƒsignalsξ˜ƒandξ˜ƒdoξ˜ƒnotξ˜ƒrequireξ˜ƒaξ˜ƒ
lineξ˜ƒconnection.ξ˜ƒToξ˜ƒmaintainξ˜ƒDECTξ˜ƒcoverageξ˜ƒduringξ˜ƒaξ˜ƒmainsξ˜ƒfailureξ˜ƒallξ˜ƒRepeatersξ˜ƒmustξ˜ƒbeξ˜ƒconnectedξ˜ƒtoξ˜ƒaξ˜ƒbatteryξ˜ƒbackedξ˜ƒ
12Vξ˜ƒDCξ˜ƒPSU.ξ˜ƒSeeξ˜ƒRepeaterξ˜ƒDeploymentξ˜ƒRulesξ˜ƒonξ˜ƒtheξ˜ƒfollowingξ˜ƒpage.ξ˜ƒ
ξ˜ƒ
REPEATER POSITIONING
ξ˜ƒ
Beforeξ˜ƒinstallingξ˜ƒpowerξ˜ƒcablesξ˜ƒtoξ˜ƒRepeaterξ˜ƒpositionsξ˜ƒitξ˜ƒisξ˜ƒimportantξ˜ƒthatξ˜ƒtheξ˜ƒoptimumξ˜ƒpositionξ˜ƒforξ˜ƒcoverageξ˜ƒisξ˜ƒestablished.ξ˜ƒ
Registerξ˜ƒtheξ˜ƒRepeaterξ˜ƒontoξ˜ƒtheξ˜ƒSoloξ˜ƒBaseξ˜ƒ(seeξ˜ƒKirkξ˜ƒProgrammingξ˜ƒKitξ˜ƒbelow)ξ˜ƒthenξ˜ƒwithξ˜ƒtheξ˜ƒRepeaterξ˜ƒpoweredξ˜ƒfromξ˜ƒaξ˜ƒbatteryξ˜ƒ
walkξ˜ƒawayξ˜ƒinξ˜ƒtheξ˜ƒdirectionξ˜ƒthatξ˜ƒcoverξ˜ƒisξ˜ƒtoξ˜ƒbeξ˜ƒextended.ξ˜ƒWhenξ˜ƒthe ξ˜ƒredξ˜ƒLEDξ˜ƒonξ˜ƒtheξ˜ƒRepeaterξ˜ƒstartsξ˜ƒtoξ˜ƒflashξ˜ƒitξ˜ƒisξ˜ƒoutξ˜ƒofξ˜ƒrangeξ˜ƒ
andξ˜ƒmustξ˜ƒbeξ˜ƒmovedξ˜ƒbackξ˜ƒtowardsξ˜ƒtheξ˜ƒSoloξ˜ƒBaseξ˜ƒbyξ˜ƒaξ˜ƒminimumξ˜ƒofξ˜ƒ5ξ˜ƒmetresξ˜ƒbeforeξ˜ƒselectingξ˜ƒitsξ˜ƒfinalξ˜ƒlocation.ξ˜ƒ
ξ˜ƒ
REPEATER PROGRAMMING
ξ˜ƒ
Aξ˜ƒKirkξ˜ƒProgrammingξ˜ƒKitξ˜ƒ(P/No.ξ˜ƒZCS729)ξ˜ƒisξ˜ƒrequiredξ˜ƒtoξ˜ƒprogramξ˜ƒRepeaters,ξ˜ƒtheξ˜ƒkitξ˜ƒconsistsξ˜ƒofξ˜ƒaξ˜ƒdoubleξ˜ƒadapterξ˜ƒandξ˜ƒcommsξ˜ƒ
leadξ˜ƒβ€“ξ˜ƒtheξ˜ƒlatestξ˜ƒServiceξ˜ƒToolξ˜ƒPCξ˜ƒsoftwareξ˜ƒandξ˜ƒuserξ˜ƒguideξ˜ƒcanξ˜ƒbeξ˜ƒdownloadedξ˜ƒfreeξ˜ƒofξ˜ƒchargeξ˜ƒfrom;ξ˜ƒ
http://support.polycom.com/PolycomService/support/us/support/voice/dect/dect_base_stations.htmlξ˜ƒ
ξ˜ƒ
REPEATER POWER CONNECTION
ξ˜ƒ
Repeatersξ˜ƒshouldξ˜ƒbeξ˜ƒconnectedξ˜ƒusing ξ˜ƒ1.0ξ˜ƒmmξ˜ƒpairξ˜ƒcabling,ξ˜ƒifξ˜ƒCW1308ξ˜ƒisξ˜ƒbeingξ˜ƒusedξ˜ƒthenξ˜ƒspareξ˜ƒpairsξ˜ƒcanξ˜ƒbe ξ˜ƒdoubled ‐upξ˜ƒ
and/orξ˜ƒloopedξ˜ƒbackξ˜ƒtoξ˜ƒformξ˜ƒaξ˜ƒringξ˜ƒcircuitξ˜ƒtoξ˜ƒreduceξ˜ƒtheξ˜ƒvoltageξ˜ƒdrop.ξ˜ƒξ˜ƒ
ξ˜ƒ
ξ˜ƒ
ξ˜ƒ
ξ˜ƒ
ξ˜ƒ
ξ˜ƒ
ξ˜ƒ
ξ˜ƒ
ξ˜ƒ
ξ˜ƒ
ξ˜ƒ
ξ˜ƒ
ξ˜ƒ
ξ˜ƒ
Typicallyξ˜ƒtheξ˜ƒmaximumξ˜ƒdistanceξ˜ƒtoξ˜ƒaξ˜ƒRepeaterξ˜ƒviaξ˜ƒCW1308ξ˜ƒshouldξ˜ƒnotξ˜ƒexceedξ˜ƒ100ξ˜ƒmetres.ξ˜ƒξ˜ƒ
ξ˜ƒ
ξ˜ƒ
ξ˜ƒ
ξ˜ƒξ˜ƒξ˜ƒMaximumξ˜ƒ6ξ˜ƒxξ˜ƒ2ξ˜ƒChannelξ˜ƒMultiξ˜ƒCellξ˜ƒRepeatersξ˜ƒ
240Vξ˜ƒ
ξ˜ƒξ˜ƒACξ˜ƒξ˜ƒ
12Vξ˜ƒDCξ˜ƒPSUξ˜ƒincludingξ˜ƒ
ξ˜ƒξ˜ƒξ˜ƒξ˜ƒξ˜ƒStandb
y
ξ˜ƒBatter
y
ξ˜ƒ
Repeaterξ˜ƒPowerξ˜ƒLeadξ˜ƒColourξ˜ƒCodeξ˜ƒξ˜ƒ
ξ˜ƒξ˜ƒξ˜ƒYELLOWξ˜ƒ=ξ˜ƒ12Vξ˜ƒξ˜ƒBLACKξ˜ƒ=ξ˜ƒ0Vξ˜ƒ
Useξ˜ƒ1.0mmξ˜ƒCableξ˜ƒ Maxξ˜ƒ100m
