Tynetec Advent xt - Lift Callpoint Installation; Surface Mount Option

DocNo.FM0410issueM‐1Page23
CALL
212.00
282.00
94.00
140.00
16.LIFTCALLPOINTINSTALLATION


TheLiftCallpoint(P/No.ZXT260)isusedto
initiateacallfrominsidealiftcar.

Thecallpointrequiresfourwiresviathelift
company’stravellingcabletoaninterface
unitinthemotorroom.

Theinterfaceunitisconnectedtothe
systemnetworksimilartoastandard
intercom.



















INSTALLATION

TheLiftCallpointisdesignedtoberetrofittedinplaceofanexistingTunstallTelecomliftunit.Itrequiresahorizontalcut‐
out212mmx94mmwith4fixingholeson216mmx106mmcentres.















ThefasciamustbeearthbondedinlinewithcurrentIEEregulations.

TERMINATION

Connecttheliftcompany’stravellingcablebetweentheLiftCallpointandtheInterfaceUnitinthemotorroom.
ConnecttheinterfaceunittotheAdventxtnetworkwiringasshownabove.
AnormallyopenmomentaryactionlowlevelKickSwitch(suppliedbyothers)canbe connectedacrosstheKICK&0V
terminalsintheliftcarasshownabove.
Setthenextavailableunique8bitbinaryaddressviaDILswitch1.

SURFACE MOUNT OPTION

TheLiftCallpointisalsoavailableinastandardAdventxtsurfacemountABSintercomcasewithintegralalarmpullcord
(P/No.ZXT271).ConnectionofthisunitisidenticaltotheZXT260above.



ADVENTxt
NETWORK
