Tynetec Advent xt - 169 Mhz SEPARATION; Aerial Connection; ID Setting

DocNo.FM0410issueM‐1Page27
KIRK400/6500
WIRELESSSERVER
BASESTATION
ORREPEATER
NETWORK
RECEIVER
NETWORK
RECEIVER
AERIAL
5METRECOAXSUPPLIEDWITHAERIAL
(DONOTEXTEND)
MINIMUM
3METRES
MINIMUM
3METRES
MINIMUM
3METRES
19.NETWORKRECEIVERINSTALLATION

169MHz SEPARATION

Toobtainmaximumcoverageitisveryimportantthatthereisaminimumof3METRESSEPARATIONbetweenthe
NetworkReceiver,itsownAerialandanyDECTBaseStationorRepeater.Failuretofollowtheserecommendationswill
resultinsignificantlyreducedradiocoverage.

















AERIAL CONNECTION

The169MHz1/2WaveAerial(P/No.W06250)comescompletewithawallmountingbracket,5metrecoaxandBNCplug 
forconnectiontotheNetworkReceiver.

Aerialsshouldbemountedvertically,ashighaspossibleandfreeofimmediateobstructionfromconcrete,steelworkor
electricalequipment.AerialsaresuitableforexternalmountingbutDONOTextendthe5metrecoaxialcablesupplied.

ID SETTING

DILswitches1to4areusedtosetauniqueID(0to15)oneachNetworkReceiver,DILswitches5to8arenotused.
ID’smustrunsequentiallystartingfromzero.

Network
ReceiverNo.
DILSwitchNo: 1 2 3 4
ID
ON=BinaryCode: “1” “2” “4” “8”
      
1

OFF OFF OFF OFF 0
2

ON OFF OFF OFF 1
3

OFF ON OFF OFF 2
4

ON ON OFF OFF 3
5

OFF OFF ON OFF 4
6

ON OFF ON OFF 5
7

OFF ON ON OFF 6
8

ON ON ON OFF 7
9

OFF OFF OFF ON 8
10

ON OFF OFF ON 9
11

OFF ON OFF ON 10
12

ON ON OFF ON 11
13

OFF OFF ON ON 12
14

ON OFF ON ON 13
15

OFF ON ON ON 14
16

ON ON ON ON 15


PROGRAMMING

ThetotalnumberofNetworkReceiversmustbesetinthe“GeneralSetup”programming‐seetheAdventxtProgramming
Manual(TynetecDocNo.FM0411).



