27.ETHERNETINTERFACEKITINSTALLATION

A00382 EXPANDER BOARD

THERCM3365/RCM3900
RABBITCOREMODULE
ISPLUGGEDONTOPOF
THEA00382BOARD




MEMORYCARDSLOT

 LED’s1‐6
 SEETABLEBELOW

RJ45ETHERNETPORT

 OPTIONSELECT
 DILSWITCH
 SEETABLEBELOW


LK1‐IPADDRESSRESET
SEENOTEBELOW


LED INDICATORS

LEDNo. Label Function
  
LED1 DEFLTADDRSET
WillbelitwhenthefactorydefaultIPaddressisset.
WillbeoutwhenasitespecificIPaddressisset.
LED2 FATMOUNTED
ShouldbelittoconfirmtheFileAllocationTable
(FAT)hasbeenmounted.IfnotlitcontactTynetec’s
CustomerSupport.
LED3 CARDFULL
WillbelitwhentheMemoryCardisdowntoitslast
5%ofstoragecapacity.Downloadthedataand
reformatthecard.
LED4 SENDINGEMAIL
WillbelitwhenanEmailisbeingsenttonotify
systemadministratorsthatsiteparametershave
beenchanged.
LED5 ‐ NoFunction
LED6 ‐ NoFunction


DIL SWITCHES

DILNo. Function
 
1 NormallyOFF‐onlyswitchONwhenun‐mountingtheMemoryCard
2 NoFunction
3 NoFunction
4 NoFunction


LK1 – IP ADDRESS RESET

Shortthe2pins“LK1”toresetthedefaultIPaddress.









