DocNo.FM0410issueM‐1Page43
ZXT130
DIGITAL COMMUNICATOR
ZXT100
ADVENT XT CONTROLLER
28.DIGITALCOMMUNICATORINSTALLATION


TheoptionalDigitalCommunicator(P/No.ZXT130)allowsthe
Adventxttocommunicatedigitallyviatheinternettoadigitally
enabledAlarmReceivingCentre(ARC).

TheAdventxtcanalsoretainthePSTNanalogueconnectionwhich
willthenbeusedasasecondaryconnection.

TheDigitalCommunicatorcanonlybeusedwith;
AdventxtmotherboardissueA‐GandfirmwareV3.01Aonwardsor
AdventxtmotherboardissueHandfirmwareV4.01Aonwards
TocheckyourfirmwareversionseeSection36.























INSTALLATION

TheDigitalCommunicatorishousedinawallmountedABSenclosure;180x180x48mm(HxWxD).
IMPORTANT:fitthe3Ferritesprovidedtothecablesasshownabove.

TERMINATION

ConnectPOWERfromtheAdventxtterminationboard12V/0Vterminalsusingthe2metre2corecableprovided.
ConnectRS232fromtheAdventxtcontroller9pinDsocket(CON1)usingthe2metredataleadprovided.
ConnectAUDIOfromtheAdventxtcontrollerJP9usingthe2metreaudioleadprovided.IMPORTANT:seeabove drawing
forcorrectorientationwhenconnectingtheaudioleadtoJP9.
ConnecttheETHERNETporttoaRouterusingthe2metreRJ45patchleadprovided.

PROGRAMMING

TheAlarmReceivingCentreIPaddressandSIPaccountdetailsmustbeenteredinthe“IP&SIPSetup”‐seetheAdventxt
ProgrammingManual(TynetecDocNo.FM0411).



Note:correctorientation
(Greenonpin5)
whenconnectingthe
AudioLeadtoJP9
