DocNo.FM0410issueM‐1Page56
34.KIRK6500DECT

FASTSWITCH CONNECTION

The16PortFastswitchprovides8PoEPorts(PoweroverEthernet)fortheIPBaseStations.

POWER‐connecttotheUPSviathein‐linePSUmodule provided.
PORTS1to8‐connecttotheIPbasestations(upto100metresof4pairCat5ecable).
PORT9‐connecttotheMatrixETHERNETportusingtheRJ45patch leadprovided.
PORT10‐connecttoKirk6500WirelessServerusinganRJ45patchlead.

Note;asecond16PortFastswitch(8xPoE)canbeconnectedtoincreasethenumberofIPbasestationsto16.
ConnectthesecondFastswitchtotheUPSandlinkthe2unitsviaaPatchLeadbetweenPorts11.
Alternativelya24PortFastswitch(24xPoE)isavailable–TynetecPartNo.ZXT559.

MATRIX CONNECTION

TheMatrixIPPBXinterfacestheAdventxttotheDECT;italsogivesaccesstoanoutsidelineandallowszoningofcalls.

24VDC‐connecttotheUPSviathein‐linePSUmoduleprovided. 
CO1‐connecttotheAdventxtDECToutputusingtheRJ11/BTleadprovided.
CO2‐connecttoanexternallineusingthesecondRJ11/BTleadprovided.
SLT1‐connecttothefixedCLIdesktelephoneviaaBTmastersocket(Note:cutoneplugofftheRJ11/RJ11leadprovided).
ETHERNET‐connecttotheFastswitchPort9usingtheRJ45patchleadprovided.
‐connecttoasoundEarthterminalusingtheEarthwireprovided

TheMatrixisfactoryprogrammedsoallincominglinesringallextensions.Ifanincominglineistoringspecificextensions
thentheMatrixmustbereconfigured.

Note;intheeventofamainsfailurei.e.iftheUPSbatteriesrunflatorifaUPSisnotfitted,theMatrixconnectsCO1toSLT1
andtheAdventxtwillonlyringthefixedCLIdesktelephone.

KIRK 6500 WIRELESS SERVER PROGRAMMING

TheMatrixmusthaveitsIPaddresssetto192.168.0.2
TheKirk6500WirelessServermusthaveitsIPaddresssetto192.168.0.3
IP12ChannelBaseStationIPaddressesmuststartat192.168.0.4withRadioPartNumbers4andcarryonsequentially.

ADVENT xt PROGRAMMING

ThePBXRingmustbeenabledinthe“GeneralSetup”programming‐seetheAdventxtProgrammingManual(TynetecDoc
No.FM0411).

4 CHANNEL MULTI CELL REPEATERS

Amaximumofthree4ChannelMultiCellRepeaterscanbeconnectedperIPBaseStation.Repeatersrequireapower
connectiononly;theycommunicatewiththeBaseStationvialowpowerradiosignals anddonotrequirealineconnection.
TomaintainDECTcoverageduringamainsfailureallRepeatersmustbeconnectedtoabatterybacked12VDCPSU.See
RepeaterDeploymentRulesonthefollowingpage.

REPEATER POSITIONING

BeforeinstallingpowercablestoRepeaterpositionsitisimportantthattheoptimumpositionforcoverageisestablished.
RegistertheRepeaterontotheIPBase(seeKirkProgrammingKitbelow)thenwiththeRepeaterpoweredfromabattery
walkawayinthedirectionthatcoveristobeextended.Whenthe redLEDontheRepeaterstartstoflashitisoutofrange
andmustbemovedbacktowardstheIPBasebyaminimumof5metresbeforeselectingitsfinallocation.

REPEATER PROGRAMMING

TheKirkProgrammingKit(P/No.ZCS729)isrequiredtoprogramRepeaters ,thekitconsistsofadoubleadapterandcomms
lead–thelatestServiceToolPCsoftwareanduserguidecanbedownloadedfreeofchargefrom;
http://support.polycom.com/PolycomService/support/us/support/voice/dect/dect_base_stations.html











