DocNo.FM0410issueM‐1Page33
22.DOORENTRYTELEPHONEINSTALLATION

Doorentrytelephones(P/No.ZFT220/221)areconnectedtotheintercomunitwithineachdwelling.Whencalledthe
telephonewillringforapresettimeoruntilthehandsetislifted.Speechisprivatebetweenthedoorpanelandthe
dwellingcalledandcannotbeoverheardbyotherusersfromtheir
handsetsorvisitorsatotherdoorpanels.




PUSHBUTTON




LEDINDICATOR










INSTALLATION

Thedoorentrytelephoneshouldbewallmountedalongside(orcloseto)theintercomunitwithineachdwelling.Unclip
thelidandscrewfixthetelephonebasetothewallusingtheholesprovided,ensurethebaseisnottwistedasthismay
preventthelidfittingcorrectly.

TERMINATION

A3pairCW1308cableisrequiredbetweenthetelephoneandtheAdventxtintercomunit.Anoptionalhardofhearing
strobelight(P/No.ZSL041)canbeconnectedtothetelephone.


OPTIONAL HARD OF HEARING
STROBE LIGHT P/No. ZSL041
MAXIMUM 2 STROBES PER FLAT:
1 TELEPHONE WITH 2 STROBES OR
2 TELEPHONES WITH 1 STROBE ON EACH
LK3 SHOULD BE IN THE “MASTER”
POSITION UNLESS A SECOND
HANDSET IS CONNECTED.
LK1 & LK2 SHOULD ALWAYS BE IN
THE “SDATA” & “SCLK” POSITIONS.
IF TWO TELEPHONES ARE REQUIRED
IN THE SAME DWELLING THEY MUST
BOTH BE ZFT221 DUAL HANDSET
MODELS.

Seetableonthefollowingpagefortherecommendedcolourcode.




Thetelephonehasasinglepushbuttonto
releasethedoorlockorselectprivacymode.

TheLEDindicatorwillilluminategreenfor
dooropenorredforprivacymode.

Privacyisprogrammableasasimpleon/off
actionorwithtimedauto‐reset
(
1to999minutes
)
.
