SARA-R4/N4 series-AT Commands Manual
UBX-17003787 - R09

7Network service
Page 50 of 307
The information text response of the read command reports only the current RAT (if any) parameters,
determined by the <rat> parameter value.
Table 4 lists the supported <mode> parameter values:
Channel <mode>=0 <mode>=2 <mode>=3 <mode>=5
SARA-N4 * *
SARA-R4 * *
Table 4: <mode> parameter applicability
7.8.2î™–î™–î™–î™–Syntax
Type Syntax Response Example
AT+UCGED=2
OK
AT+UCGED=3
+UCGED: 0
65535,fff,fff,0000,ff,99
10588,1,222,88,1281d24,255,11,40
65535,255,255,255,fff,fff,ffff,0000
000,65535,255,255,255,255
OK
Set AT+UCGED=<mode> [+UCGED: <svc>
<arfcn>,<Gmcc>,<Gmnc>,<GcellId>,
<BSIC>,<rxlev>
<uarfcn>,<Wband>,<Wmcc>,
<Wmnc>,<WcellId>,<Wrrc>,<rssi>,
<ecn0_lev>
<earfcn>,<Lband>,<ul_BW>,<dl_
BW>,<Lmcc>,<Lmnc>,<tac>,
<LcellId>,<P-CID>,<rsrp>,<rsrq>,
<Lsinr>,<Lrrc>]
OK
AT+UCGED=5
OK
<mode>= 0:
+UCGED: 0
OK
+UCGED: 0
OK
<mode>= 2, <rat>= 2:
+UCGED: 2
2,<svc>,<MCC>,<MNC>
<arfcn>,<band1900>,<GcellId>,
<BSIC>,<Glac>,<Grac>,<rxlev>,
<grr>,<t_adv>,<Gspeech_mode>
OK
+UCGED: 2
2,4,001,01
810,1,0000,01,0000,80,63,255,255,
255
OK
<mode>= 2, <rat>= 3:
+UCGED: 2
3,<svc>,<MCC>,<MNC>
<uarfcn>,<Wband>,<WcellId>,
<Wlac>,<Wrac>,<scrambling_
code>,<Wrrc>,<rssi>,<ecn0_lev>,
<Wspeech_mode>
OK
+UCGED: 2
3,4,001,01
4400,5,0000000,0000,80,9,4,62,42,
255
OK
Read AT+UCGED?
<mode>= 2, <rat>= 4:
+UCGED: 2
4,<svc>,<MCC>,<MNC>
<earfcn>,<Lband>,<ul_BW>,
<dl_BW>,<tac>,<LcellId>,<P-
CID>,<mTmsi>,<mmeGrId>,
<mmeCode>, <rsrp>,<rsrq>,
<Lsinr>,<Lrrc>,<RI>,<CQI>,
<avg_rsrp>,<totalPuschPwr>,
<avgPucchPwr>,<drx>, <l2w>,
<volte_mode>[,<meas_gap>,<tti_
bundling>]
+UCGED: 2
4,0,001,01
2525,5,25,50,2b67,69f6bc7,111,0000
0000,ffff,ff,67,19,0.00,255,255,255,
67,11,255,0,255,255,0,0
OK
