UNI-T UTG9000T Series User Manual

UTG9000T Series Function Abitrary Waveform Generator
100
Tap Freq to pop-out visual keyboard to enter 2kHz.
Tap Ampl to pop-out visual keyboard to enter 2Vpp.
3) Set the modulation parameter
After the parameter setting of the carrier wave, tap Type to return to modulation interface to
set parameter.
Tape IQMap→QAM4 to select QAM64.
Tape PN Code→PN3 to select PN7.
Tape Bitrate to pop-out visual numeric keyboard to enter 100bps（the default 100bps）
