UTG9000T Series Function Abitrary Waveform Generator

3.1.11 OSK (Oscillation Keying)

The function/arbitrary waveform generator can output a sinusoidal signal of intermittent oscillation

in OSK. The carrier waveform is output when internal crystal oscillator starts oscillation; output is

stopped when internal crystal oscillator stops oscillation. The modulation modes for each channel

are independent, it can set the same or different modulation modes to each channel.

Select OSK modulation

Tap CH1→Modulate→QSK to turn on OSK modulation, the instrument output the moduluated waveform

according to the current setting of the modulation wave and the carrier wave.

Select the carrier waveform

OSK carrier waveform is sine wave.
