3.1.3 PM (Phase Modualtion)
PM is consist of the carrier wave and the modulated wave, the phase of the carrier wave will
changed by the phase of the modulated wave. The modulation modes for each channel are
independent, it can set the same or different modulation modes to each channel.
Select PM modulation
Tap CH1→Modulate→PM to turn on the AM modualtion, the instrument output the moduluated
waveform according to the current setting of the modulation wave and the carrier wave.
Select the carrier waveform
The carrier wave of PM: sine, square, ramp, pulse and arbitrary wave (except DC), the default option is
sine wave. After select PM modulation, tap Base to present the carrier waveform on the right side.
