Appendix A：Factory Setting
Parameter
Factory Default Setting
Channel Parameter
Current carrier wave Sine wave
Output load
High resistance
Channel merge
Off
Channel coupling
Off
Sync output
Off
Channel output
Off
Channel output inverse
Off
Amplitude limit
Off
Upper amplitude limit
+1V
Lower amplitude limit -1V
Fundamental Wave
Frequency 1kHz
Amplitude 100mVpp
DC offset
0mV
Initial phase 0°
Duty ratio of square wave
50%
Degree of symmetry of ramp wave 100%
Duty ratio of pulse wave 50%
Rising edge of pulse wave 1.4ns
Falling edge of pulse wave
1.4ns
Arbitrary Wave
Built-in arbitrary wave ACos
Play mode DDS
AM Modualtion
Modulation source Internal
Modulation wave
Sine wave
