3.4.4 Create and edit arbitrary waveform
The powerful upper computer software can be used to create and edit cpmplex arbitrary
waveform (arbitrary amplitude and shape). For specific operations, please refer to UTG9000T
Abritrary Waveform Programming Guide. The created arbitrary waveform can import to the
function/arbitrary waveform generator.
3.5 Output Digital Protocol
The waveform generator can output three types of protocol conding: IIC, SPI and UART. (TTL)
The corresponding protocol parameters can be set in different protocol modes. Turn on output
terminal on the front panel to export the corresponding signal.
3.5.1 SPI Protocol
The waveform generator can create configurable SPI protocol signal parameters in SPI protocol
mode.
Select SPI mode
Tap Utility → Digital → SPI accordingly, turn on SPI mode to output the current SPI protocol
signal.
