UTG9000T Series Function Abitrary Waveform Generator
131
Clock setting
The sending clock of SPI can set by user’s need. In SPI mode, tap Clock to pop-out visual
numeric keyboard to enter values and select unit. The clock range can set to 1Hz~50MHz.
Data format setting
The data format of SPI can set by user’s need. It have two format types: hexadecimal and character.In SPI
mode, tap Format to step through HEX and Char.
Set data
Tap blank input box on the right side to pop-out visual numeric keyboard to enter bits and tap return key
to complete an entry.
