UNI-T UTG9000T Series User Manual

UTG9000T Series Function Abitrary Waveform Generator
152
set the phase according to the selected harmonic serial number
Overlay amplitude of
noise
noise voltage ≤1Vrms
Output Characteristics
Amplitude range
Load：HighZ
(50Ω load is the
half of HighZ)
≤40MHz:2mVpp
～
20Vpp
≤120MHz:2mVpp～10Vpp
≤160MHz: 2mVpp
～
5Vpp
≤300MHz: 2mVpp～4Vpp
≤400MHz: 2mVpp
～
2.5Vpp
≤500MHz: 2mVpp～1.5Vpp
≤600MHz: 2mVpp
～
1Vpp
Accuracy（1kHz
Sine wave）
(1kHz sine wave，0V deviation, >10mVpp)
±（amplitude value 1%+1mVpp）
Amplitude flatness
（
v
ersus to 1kHz sine
wave，1Vpp/50Ω）
≤10MHz
，
0.1dB
≤160MHz，0.2dB
≤350MHz
，
0.4dB
≤500MHz，0.8dB
≤600MHz
，
0.8dB
Output Waveform
Impedance
50Ω typical vaule
Protection Channel protection
Modualtion Type
AM Modualtion
Carrier wave Sine, square, pulse, ramp, arbitrary wave
Source
Internal/external
Modulation wave Sine, square, rising ramp, falling ramp, noise, arbitrary wave
Modulation frequency
1μHz
～
2MHz
1μHz
～
1MHz
Modulation depth
0%～120%
FM Modualtion
Carrier wave Sine, square, pulse, ramp, arbitrary wave
Source
Internal/external
Modulation wave Sine, square, rising ramp, falling ramp, noise, arbitrary wave
Modulation frequency
1μHz
～
2MHz
1μHz
～
1MHz
Frequency deviation DC-
300MHz
DC-
100MHz
DC-
200MHz
DC-
80MHz
DC-
100MHz
DC-
60MHz
