Note: The coupling setting of CH3 to CH4 is the same as CH1 coupling to CH2.
Tap Utility➡Coupling to make the relevant settings:
1. Frequency Coupling
The frequency coupling mode to set ratio or deviation. CH1 and CH2 are each other's reference
sources, change one of the channel’s (as the reference source) frequency counter, the other
channel will adjustment automatically. And always maintain the specified ratio/deviation of the
reference channel.
Ratio: the specific value of CH2：CH1; Deviation: the difference value of CH2-CH1. The
frequency settings to set CH3 coupling to CH4 is the same as CH1 coupling to CH2.
Tap Freq to step through OFF/ON.
Tap Type to step through Ratio/Deviation.
Ratio type: tap CH2:CH1 tab, pop-out the virtual numeric keyboard to enter numbers and tap
return key.
Deviation type: tap CH2:CH1 tab, pop-out the virtual numeric keyboard to enter numbers and
tap return key.
2. Amplitude Coupling
The amplitude coupling mode to set ratio or deviation. CH1 and CH2 are each other's reference
sources, change one of the channel’s (as the reference source) amplitude, the other channel
will adjustment automatically. And always maintain the specified ratio/deviation of the reference
channel.
Ratio: the specific value of CH2：CH1; Deviation: the difference value of CH2-CH1. The
amplitude settings of CH3 coupling to CH4 is the same as CH1 coupling to CH2.
Tap Ampl to step through OFF/ON.
Tap Type to step through Ratio/Deviation.
Ratio type: tap CH2:CH1 tab, pop-out the virtual numeric keyboard to enter numbers and tap
return key.
Deviation type: tap CH2:CH1 tab, pop-out the virtual numeric keyboard to enter numbers and
tap return key.
3. Phase Coupling
The phase coupling mode to set ratio or deviation. CH1 and CH2 are each other's reference
sources, change one of the channel’s (as the reference source) phase, the other channel will
adjustment automatically. And always maintain the specified ratio/deviation of the reference
channel.
Ratio: the specific value of CH2：CH1; Deviation: the difference value of CH2-CH1. The phase
