UNI-T UTG9000T Series User Manual

UTG9000T Series Function Abitrary Waveform Generator
45
2）Set the parameter of modulating signal
Base on the step 1) to tap ModFreq tab to pop-out visual numeric keyboard to enter 2kHz.
3）Set the parameter of the carrier wave signal
Tap Base to select sine as the carrier wave (the default option is sine), so this step has no
change.
Tap Freq to pop-out visual keyboard to enter 10kHz.
4）Set the frequency deviation
After the parameter setting of the carrier wave, tap Type to return to modulation interface
to set the frequency deviation.
