Select the carrier waveform
The carrier wave of AM: sine, square, ramp, pulse and arbitrary wave (except DC), the default
option is sine wave. After select ASK modulation, tap Base to present the carrier waveform on the
right side.
Carrier wave frequency settings
Refer to The carrier wave frequency settings of AM modulation.
Select the source of modulation
UTG9000T function/arbitrary waveform generator can select internal or external modulation source.
When turn on FM modulation, the default modulation source is internal. Rotate multifunction knob or tap
ModSrc tab to step through internal or external modulation source in ASK modulation setting interface.
