UNI-T UTG9000T Series User Manual

UTG9000T Series Function Abitrary Waveform Generator
60
Tap Freq to pop-out visual keyboard to enter 2kHz.
Tap Ampl to pop-out visual keyboard to enter 1Vpp.
3) Set the hopping frequency and the modulating frequency
After the parameter setting of the carrier wave, tap Type to return to modulation interface to
set the modulating frequency.
Tap ModFreq to pop-out visual keyboard to enter 200Hz.
Tap HopFreq1 to pop-out visual keyboard to enter 800Hz.
4) Turn on the output channel
Tap channel Out botton to ON or push CH1 key on the front panel to quick set the output
channel,and it can aslo turn on at the Utility interface,tap Utility→Channel→Output or
double-click the channel tab at the bottom of the screen to step through ON/OFF. CH1 key
and CH1 tab backlight light on indicating that the channel 1 output is turned on.

UNI-T UTG9000T Series Specifications

General

Brand	UNI-T
Model	UTG9000T Series
Category	Portable Generator
Language	English
