UTG9000T Series Function Abitrary Waveform Generator

Select the carrier waveform

The carrier wave of 3FSK: sine, square, ramp, pulse and arbitrarty wave (except DC), the default

option is sine wave. After select 3FSK modulation, tap Base to present the carrier waveform on

the right side.

Carrier wave frequency settings

Refer to The carrier wave frequency settings of AM modulation.

Hopping frequency settings

Rotate multifunction knob, push direction key or tap HopFreq1 and HopFreq2 tab to pop-out

visual numeric keyboard to enter values and select unit in 3FSK modulation setting interface. The

range of hopping frequency depends on carrier waveform. Refer to Tabe 4-1/4-2 of AM

modulation.
