UTG9000T Series Function Abitrary Waveform Generator

Select the carrier waveform

The carrier wave of PSK: sine, square, ramp and arbitrarty wave (except DC), the default option is

sine wave. After select PSK modulation, tap Base to present the carrier waveform on the right

side.

Carrier wave frequency settings

Refer to The carrier wave frequency settings of AM modulation.

Select the source of modulation

UTG9000T function/arbitrary waveform generator can select internal or external modulation source.

When turn on PSK modulation, the default modulation source is internal. Rotate multifunction knob or

tap ModSrc tab to step through internal or external modulation source in PSK modulation setting

interface.
