UTG9000T Series Function Abitrary Waveform Generator
98
Select the carrier waveform
QAM carrier waveform is sine wave. After select QAM modulation, tap Base to present the carrier
waveform on the right side.
Carrier wave frequency settings
Refer to The carrier wave frequency settings of AM modulation.
Modulation type
The modulation type, which is the division of the constellation changed by the modulation types.
Rotate multifunction knob or tap IQMap→QAM4 to step through QAM4, QAM8, QAM16, QAM32,
QAM64, QAM128, and QAM256M.
