Unitec Wash Select II User Manual

W A S H S E L E C T I I
Document Number: WS21002 166
Document Title: WSII Operations Manual
J19 Fault/Warning Outputs
Pin
Description
1
Fault output Common (dry contact) 500ma max
2
Fault output Normally Open (dry contact) 500 ma max
3
Warning output Common (dry contact) 500 ma max
4
Warning output Normally Open (dry contact) 500ma max
J18 Wash Inputs
Pin
Description
1
Wash In Use Hot (20-120VAC/DC)
2
Wash In Use Neutral
3
Wash Fault Hot (20-120VAC/DC)
4
Wash Fault Neutral
5
Wash Warning Hot (20-120VAC/DC)
6
Wash Warning Neutral
J17 Wash Relays
Pin
Description
1
Program relay 1 output (500mA max)
2
Program relay 2 output (500mA max)
3
Program relay 3 output (500mA max)
4
Program relay 4 output (500mA max)
5
Program relay 5 output (500mA max)
6
Program relay 6 output (500mA max)
7
Program relay 7 output (500mA max)
8
Program relay 8 output (500mA max)
9
Program relay Common
10
N/C

Unitec Wash Select II Specifications

General

Brand	Unitec
Model	Wash Select II
Category	Touch terminals
Language	English
