• The green START button begins processing the selected job.
• The PAUSE button stops the engraving process. Pressing the PAUSE button again resumes the
engraving process where it was last stopped.
• The four navigation buttons move the focus carriage manually in X and Y.
• The two up and down buttons move the Z-Axis table up or down.
• The Home XY button re-homes the focus carriage to the upper right-hand corner of the field.
• The Home Z button re-homes the Z-Axis table to the bottom of the laser system.
View Tab Modes
Icons allow you to select from various modes of operation for the preview screen.
Basic View (default mode)
• The Basic View shows a preview window of the job currently selected.
• The cursor becomes a magnifying glass (Zoom Tool) if you pass it over the preview window. Left-
clicking the mouse zooms in and right-clicking zooms out. (Mouse scroll wheel can be used in
any mode to zoom in and out.)
• Selecting the Settings button takes you back to the printer driver interface to allow you to
change most of the settings for the job selected. Keep in mind that some settings cannot be
changed after printing from your graphics program such as print density and vector quality. If a
setting is not adjustable after printing from your graphics program, it will be grayed out or not
appear at all when you press the settings button in the UCP.
Focus View
• The Focus View allows you to quickly manually move the focus carriage to a desired position in
the material processing field.
• To have full range of motion, verify that you are zoomed out in the preview window by right-
clicking on the mouse before entering the manual focus window.
• In the focus view the cursor changes to a blue target symbol with trailing X-Y coordinates.
Clicking the mouse in the preview window moves the focus carriage to the selected position.
Selecting another feature from the dropdown list terminates the focus feature and moves the
focus carriage back to the home position.
• To move the focus carriage to a specific location, select the GO button. Type in the X and Y
coordinates and press the GO TO button and the focus carriage will move to the specified
location. You can also move the engraving table to a specific Z-height using the GO feature.
Relocate View
The Relocate feature gives you the ability to move the image in the selected job to another area of the
engraving field. This feature does not permanently modify the original image location.
When this feature is activated, the image is surrounded by nine small squares (anchor points)
representing the center and extents of the graphic. Using these anchors, you can relocate the image in
one of three ways:
1. You can select and hold an anchor point and drag that anchor to move the image around in the
field.
2. You can select an anchor point and type a new X-Y coordinate for that anchor point in the X-Y
fields to the right of the preview screen.
3. Using the X-Y manual motion buttons, you can move the focus carriage to a location on the
processing table in the laser system using the red pointer diode as reference, then select an
