2DA/2DB

7. Remove the three screws and then remove the

ejection cover and inner ejection cover.

8. Remove the two screws and then remove the cover.

Screws

Screw

Ejection cover

Inner ejection cover

Screws

Cover

Figure 1-3-41

Figure 1-3-42
