Configuration and Programming
February 2011 3-28 P/N 06-237041-001
delay period. Each monitor module with address within the range of 106 through 110 will be
assigned as an abort station.
• Each AO output module with address within the range of 111 to 115 will be assigned as a pre-
alarm output point.
• Each AO output module with address within the range of 116 to 120 will be assigned as a pre-
release output point.
• Each AO output module with address within the range of 121 to 125 will be assigned as a release
output point.
Sequence of Operation
The FenwalNET 8000-ML will progress through the pre-alarm, pre-release, and release states as
defined in Table 4-5. The time delay between the pre-release and the release states will be 30 seconds.
Control-Unit-Based Outputs Assignments
Control-unit-based outputs will be assigned to the pre-alarm, pre-release, and release states as
follows:
Pre-Alarm State
NAC No. 1 (steady activation)
Programmable Relay No. 1
The owner-location field on the LCD will display the word "Pre-Alarm"
Pre-Release State
NAC No. 2 (steady activation)
Programmable Relay No. 2
The owner-location field on the LCD will display the word "Pre-Release" concurrently with the
continuously-decremented countdown timer
Deactivate NAC No. 1
Release State
Release Circuit No. 1
Release Circuit No. 2
Combination NAC/Releasing Output No. 1 as a NAC (steady activation)
Combination NAC/Releasing Output No. 2 as a release circuit
Programmable Relay No. 3
The owner-location field on the LCD will display the word "Agent Release"
CAUTION
Owner locations are not assigned during the AutoSetup Procedure. The Abort operation
in this setup is not UL Listed.
