UTC Fire and Security FenwalNET 8000-ML User Manual

Configuration and Programming
February 2011 3-34 P/N 06-237041-001
Figure 3-28. FenwalNET 8000-ML Set Menu Functions (Cont’d - Fig. 12 of 14)
3. SET
Cont’d
After final parameter, the following appears:
BATTERY CONFIGURATION
PRESS ‘0’ TO EDIT THE PARAMETER
PRESS ENTER TO SELECT THE VALUE
PRESS <- TO EXIT THE CONFIG
BATTERY CONFIGURATION
CURRENT VALUE
SUPERVISE BATTERIES
YES
PRESS ‘0’ TO CHANGE SETTING
BATTERY CONFIGURATION
USE SCROLL FOR OPTIONS, ENTER TO SELECT
CIRCUIT:
DISABLE
BATTERY CONFIGURATION
USE SCROLL FOR OPTIONS, ENTER TO SELECT
END OF CONFIGURATION, SAVE?:
YES
4: SUPERVISE BATTERY
40
4. PMU
*= Level-2 (Installer) Password required .
1. Battery Disp Enable 
2. BATTERY DISPLAY
2. Battery Disp Disable 
OLD REPLACEMENT DATE (MMDDYY): mmddyy
NEW REPLACEMENT DATE (MMDDYY): _____

3. BATT REPLACE DATE
3
4
BACKPLANE CONFIGURATION
PRESS ‘0’ TO EDIT THE PARAMETER
PRESS ENTER TO SELECT THE VALUE
PRESS <- TO EXIT THE CONFIG
ENTER MODULE LOGICAL ADDRESS:__ 
PMU
CURRENT VALUE
OWNER LOCATION:
RNAC Module Owner Location
RELAY MODULE # (X) CIRCUIT: # (X)
USE SCROLL FOR OPTIONS, ENTER TO SELECT
CIRCUIT:
DISABLE
PRESS ENTER TO VIEW NEXT SETTING
RELAY MODULE # (X) CIRCUIT: # (X)
USE SCROLL FOR OPTIONS, ENTER TO SELECT
END OF CONFIGURATION, SAVE?:
YES
After final parameter, the following appears:
1: PMU SETTINGS
PRESS ‘0’ TO CHANGE SETTING
*
6. OUTPUTS/BACKPLANE
2. BACKPLANE
BACKPLANE CONFIGURATION
PRESS ‘0’ TO EDIT THE PARAMETER
PRESS ENTER TO SELECT THE VALUE
PRESS <- TO EXIT THE CONFIG
CITY TIE
CURRENT VALUE
OWNER LOCATION:
CITY TIE Module Owner Location
PRESS ‘0’ TO CHANGE SETTING
CITY TIE
USE SCROLL FOR OPTIONS, ENTER TO SELECT
CIRCUIT:
DISABLE
PRESS ENTER TO VIEW NEXT SETTING
CITY TIE
USE SCROLL FOR OPTIONS, ENTER TO SELECT
END OF CONFIGURATION, SAVE?:
YES
3. CITY TIE
