Figure 3-27. FenwalNET 8000-ML Set Menu Functions (Cont’d - Fig. 11 of 14)
3. SET
Cont’d
*
*= Level-2 (Installer) Password required .
6. OUTPUTS/BACKPLANE
2. BACKPLANE
1. RNAC
BACKPLANE CONFIGURATION
PRESS ‘0’ TO EDIT THE PARAMETER
PRESS ENTER TO SELECT THE VALUE
PRESS <- TO EXIT THE CONFIG
ENTER MODULE LOGICAL ADDRESS:__ 
RNAC MODULE # (X)
CURRENT VALUE
OWNER LOCATION:
RNAC Module Owner Location
RNAC MODULE# (X)
PRESS CIRCUIT NUMBER (1 / 2 / 3)
RNAC MODULE # (X) CIRCUIT: # (X)
CURRENT VALUE
CIRCUIT:
DISABLE
PRESS ‘0’ TO CHANGE SETTING
RNAC MODULE # (X) CIRCUIT: # (X)
USE SCROLL FOR OPTIONS, ENTER TO SELECT
CIRCUIT:
DISABLE
PRESS ENTER TO VIEW NEXT SETTING
RNAC MODULE # (X) CIRCUIT: # (X)
USE SCROLL FOR OPTIONS, ENTER TO SELECT
END OF CONFIGURATION, SAVE?:
YES
After final parameter, the following appears:
2. RELAY
BACKPLANE CONFIGURATION
PRESS ‘0’ TO EDIT THE PARAMETER
PRESS ENTER TO SELECT THE VALUE
PRESS <- TO EXIT THE CONFIG
ENTER MODULE LOGICAL ADDRESS:__ 
RELAY MODULE # (X)
CURRENT VALUE
OWNER LOCATION:
RNAC Module Owner Location
RELAY MODULE# (X)
PRESS CIRCUIT NUMBER (1 / 2 / 3 / 4)
RELAY MODULE # (X) CIRCUIT: # (X)
CURRENT VALUE
CIRCUIT:
ENABLE
PRESS ‘0’ TO CHANGE SETTING
RELAY MODULE # (X) CIRCUIT: # (X)
USE SCROLL FOR OPTIONS, ENTER TO SELECT
CIRCUIT:
DISABLE
PRESS ENTER TO VIEW NEXT SETTING
RELAY MODULE # (X) CIRCUIT: # (X)
USE SCROLL FOR OPTIONS, ENTER TO SELECT
END OF CONFIGURATION, SAVE?:
YES
After final parameter, the following appears:
