UTC Fire and Security FenwalNET 8000-ML User Manual

Configuration and Programming
February 2011 3-32 P/N 06-237041-001
Figure 3-26. FenwalNET 8000-ML Set Menu Functions (Cont’d - Fig. 10 of 14)
3. SET
Cont’d
6. OUTPUTS/BACKPLANE
1. ONBOARD
*
*= Level-2 (Installer) Password required .
2. BACKPLANE
ONBOARD CONFIGURATION
PRESS ‘0’ TO EDIT THE PARAMETER
PRESS ENTER TO SELECT THE VALUE
PRESS <- TO EXIT THE CONFIG
PRESS ‘0’ TO CHANGE SETTING
PRESS ENTER TO VIEW NEXT SETTING
ONBOARD NAC # (X)
USE SCROLL FOR OPTIONS, ENTER TO SELECT
END OF CONFIGURATION, SAVE?
YES
After final parameter, the following appears:
1: NACs
ENTER CIRCUIT NUMBER (1 / 2)
ONBOARD NAC # (X)
CURRENT VALUE
CIRCUIT:
ENABLE
ONBOARD NAC # (X)
USE SCROLL FOR OPTIONS, ENTER TO SELECT
CIRCUIT:
DISABLE
After final parameter, the following appears:
2. RNACs
ONBOARD CONFIGURATION
PRESS ‘0’ TO EDIT THE PARAMETER
PRESS ENTER TO SELECT THE VALUE
PRESS <- TO EXIT THE CONFIG
PRESS CIRCUIT NUMBER (1 / 2) _
ONBOARD RNAC# (X)
CURRENT VALUE
CIRCUIT:
ENABLE
PRESS ‘0’ TO CHANGE SETTING
ONBOARD RNAC# (X)
USE SCROLL FOR OPTIONS, ENTER TO SELECT
CIRCUIT:
DISABLE
PRESS ENTER TO VIEW NEXT SETTING
ONBOARD RNAC# (X)
USE SCROLL FOR OPTIONS, ENTER TO SELECT
END OF CONFIGURATION, SAVE?
YES
3. RELAYS
PRESS ‘0’ TO CHANGE SETTING
ONBOARD RELAY# (X)
USE SCROLL FOR OPTIONS, ENTER TO SELECT
CIRCUIT:
DISABLE
ONBOARD CONFIGURATION
PRESS ‘0’ TO EDIT THE PARAMETER
PRESS ENTER TO SELECT THE VALUE
PRESS <- TO EXIT THE CONFIG
PRESS CIRCUIT NUMBER (1 / 2 / 3)
ONBOARD RELAY# (X)
CURRENT VALUE
CIRCUIT:
ENABLE
PRESS ENTER TO VIEW NEXT SETTING
ONBOARD RELAY# (X)
USE SCROLL FOR OPTIONS, ENTER TO SELECT
END OF CONFIGURATION, SAVE?
YES
After final parameter, the following appears:
See next Figure.
