UTC Fire and Security FenwalNET 8000-ML User Manual

Configuration and Programming
P/N 06-237041-001 3-45 February 2011
Figure 3-35. FenwalNET 8000-ML Test Menu Functions (Cont’d - Fig. 5 of 5)
FOOTNOTES (Figure 3-35):
10 SLC Resistance. Measure SLC Resistance. Purpose: To measure the SLC line resistance.
Note: The SLC line resistance cannot be measured for CLASS-B SLCs with T-Tapping.
11 Find Dup Address. How to Find a Duplicate Address.
Purpose: To clear the trouble message that appears when two SLC devices have been accidentally
assigned the same address. The location of the affected SLC devices can be found by instructing the
control unit to modify the doubly addressed devices LED pulse pattern.
Note: Only one address can be selected at a time if more than one double-address trouble exists.
4. TEST
9. Diagnostics
2. SLC Resistance
SLC Line Resistance ____ohms
3. SLC Comm Value
*
SLC Communication Value
SLC Devices From *__ To ___
 (1-255)
*= Level-2 (Installer) Password required .
4. SLC Loop Debug
5. SLC Comm Debug
10
1. Reset Modules
Enter Physical Slot Range:__to__
Enter 00 to 00 for Broadcast Reset
SLC Module Selection
Enter SLC Module Number (1-8):__
SLC Module Selection
Enter SLC Module Number (1-8):__
SLC Loop Debug
Enter SLC Module Number (0-8):__
SLC Comm Debug
Enter SLC Module Number (0-8):__
6. SLC Debug Off
SLC Debug Off
Enter SLC Module Number (0-8):__
SLC Double Address Detector LED Utility
Enter SLC Address * ___
 (000-255)
SLC Double Address Detector LED Utility
Press Backspace to Exit
SLC Module Selection
Enter SLC Module Number (1-8):__
8. Find Dup Address
*
11
