Wiring Requirements for FenwalNET 8000-ML Signaling Line Circuit
P/N 06-237041-001 B-1 February 2011
APPENDIX B
WIRING REQUIREMENTS FOR FENWALNET 8000-ML
SIGNALING LINE CIRCUIT
B-1 RECOMMENDED WIRE TYPES
For best results, use twisted, unshielded, low-capacitance, addressable-fire-alarm wire with a nominal
wire-to-wire capacitance of approximately 20 pf (picofarads, where 1 pf = 10
-6
F) per foot for the
signaling line circuit. Typical wire types that meet these criteria are indicated below:
Table B-1. Typical Wire Types - 18 AWG
Manufacturer Part Number Rating Capacitance (pf/ft.)
Atlas Wire and Cable Corp. 228-18-1-1TP FPL 12.5
West Penn Wire D980 FPL 16.0
West Penn Wire 60980B FPLP 29.0
Coleman Cable 98181 FPL 19.0
Coleman Cable 98820 FPLR 26.0
Clifford of Vermont, Inc. 1P18 B1 FPL-M FPL 15.0
Comtran Corporation 4184 FPLR 20.0
Belden Wire and Cable Co. 5320UJ FPL 12.5
Belden Wire and Cable Co. 9571 FPLR 22.0
Belden Wire and Cable Co. 6320UJ FPLP 25.0
BSCC 341802E FPLP 25.0
Genesis Cable Systems 4050 FPL 15.0
Genesis Cable Systems 4431 FPLR 15.0
Genesis Cable Systems 4631 FPLP 16.0
