Wiring Requirements for FenwalNET 8000-ML Signaling Line Circuit
February 2011 B-2 P/N 06-237041-001
Table B-2. Typical Wire Types - 16 AWG
Manufacturer Part Number Rating Capacitance (pf/ft.)
Atlas Wire and Cable Corp. 228-16-1-1TP FPL 12.5
West Penn Wire D990 FPL 18.0
Coleman Cable 98161 FPL 20.0
Coleman Cable 98620 FPLR 27.0
Clifford of Vermont, Inc. 1P16 B1 FPL-M FPL 19.0
Comtran Corporation 4234 FPLR 20.0
Belden Wire and Cable Co. 5220UJ FPL 13.5
Belden Wire and Cable Co. 9572 FPLR 29.0
Belden Wire and Cable Co. 6220UJ FPLP 27.0
BSCC 341602E FPLP 18.0
Genesis Cable Systems 4051 FPL 17.0
Genesis Cable Systems 4432 FPLR 17.0
Genesis Cable Systems 4632 FPLP 18.0
Table B-3. Typical Wire Types - 14 AWG
Manufacturer Part Number Rating Capacitance (pf/ft.)
Atlas Wire and Cable Corp. 228-14-1-1TP FPL 14.5
Coleman Cable 98141 FPL 20.0
Coleman Cable 98420 FPLR 25.0
Comtran Corporation 4240 FPLR 21.0
Belden Wire and Cable Co. 9580 FPLR 27.0
Belden Wire and Cable Co. 6120UJ FPLP 25.9
BSCC 341402E FPLP 20.0
Genesis Cable Systems 4052 FPL 19.0
Genesis Cable Systems 4433 FPLR 19.0
Genesis Cable Systems 4633 FPLP 20.0
Table B-4. Typical Wire Types - 12 AWG
Manufacturer Part Number Rating Capacitance (pf/ft.)
Coleman Cable 98121 FPL 27.0
Coleman Cable 98200 FPLR 29.0
Genesis Cable Systems 4054 FPL 21.0
Genesis Cable Systems 4434 FPLR 22.0
