UTC Fire and Security FenwalNET 8000-ML User Manual

List of Agency Listed Compatible Devices
P/N 06-237041-001 C-3 February 2011
* Must be used in conjunction with Microswitch P/N 87-120039-001 for momentary operation.
Table C-3. Releasing Devices - Initiator-Based
* The total circuit resistance for the 31-199932-004 and 93-191001-001 devices must be 10 + 1 ohms, regardless of
the number used. The total circuit resistance (including field wiring) for the 93-002009-004 device should be
adjusted to be at least 10 ohms, not to exceed 13.6 ohms.
The firing current will be 2.5 Amps.
Device Model and
Part Number
I
(Max.)
Amps
Resistance
(Min.)
Ohms
“On” Time
12
AWG
14
AWG
16
AWG
18
AWG
Max.
No.
p e r
R-NAC
Circuit
Max.
No
per
RRM
Agency
For FM Systems:
Kidde-Fenwal
Sol. P/N
06-118329-001
0.225 108.0 Steady 3000 2000 1200 800 1 1 or 2 FM
Marioff
3-101-46A/2
(D21070)
0.92 26.0 Steady 483 327 190 — 1 1 FM
FM Group A 0.458 52.0 Steady 1440 760 480 340 1 1 FM
FM Group B, D 0.7 34.0 Steady 940 500 300 220 1 1 FM
FM Group E, G 0.42 57.0 Steady 1570 760 525 370 1 1 FM
FM Group F Skinner 24 Vdc, 22 Watt Solenoid 7312BN4TNLVNOC322C2 1 1 FM
FM Group I Victaulic 24 Vdc, 8.7 Watts, 364 mA series 753-E Solenoid 1 1 FM
FM Group J Viking Model No. 11591, 11592, 11595, and 11596, 24 Vdc, 10
Watts
11FM
FM Group K Viking Model No. 11601, 11602, and 13215, 24 Vdc, 9 Watts 1 1 FM
Device
I (Max.)
Amps
Resistance
(Min.) Ohms
“On” Time
Max. Number per
R-NAC Circuit
Agency
93-002009-004 * 1.6 Momentary 8 FM
31-199932-004 * — Momentary 12 UL, FM
93-191001-001 * — Momentary 6 UL, FM
Table C-2. Releasing Devices - Solenoid-Based
Wire Length (ft.)
